John Deere XUV590E

Engine power

23.8* kW
32 hp

Cargo box dimensions

82L x 120.9W x 29.7D (0.25 m3) cm
32.3L x 47.6W x 11.7D (8.9 ft3) in.

Cargo box capacity (weight)

227 kg
500 lb

Towing capacity

1500 lb
680 kg

Front suspension

Fully independent dual A-Arm with adjustable coil over shocks, 8 in. (203 mm) travel, Anti-roll bar

Rear suspension

Fully independent with lower A-arm and upper camber link with adjustable coil over shocks, 8 in. (203 mm) travel

Final drive

High, Low, Neutral, Reverse Transaxle

Four wheel drive

Dash lever actuated four-wheel drive system with limited slip front differential, plus locking rear differential

Fuel capacity

28 L
7.4 U.S. gal.

Type

4-cycle gas, Inline-twin, Electronic Fuel Injection (EFI), Overhead Valves (OHV)

Displacement

586 cc

Power

23.8* kW
32 hp

Cooling system

Liquid cooled

Transmission

Continuously Variable Transmission (CVT) with clutch enclosure

Final drive

High, Low, Neutral, Reverse Transaxle

Four wheel drive

Dash lever actuated four-wheel drive system with limited slip front differential, plus locking rear differential

Traction assist

Positive locking, mechanically actuated (hand lever operated) rear differential lock

Descent control

Not available

Front

Fully independent dual A-Arm with adjustable coil over shocks, 8 in. (203 mm) travel, Anti-roll bar

Rear

Fully independent with lower A-arm and upper camber link with adjustable coil over shocks, 8 in. (203 mm) travel

Type

196 mm ventilated four-wheel stainless steel disc brakes with hydraulic 1.375 in. (34.93mm) diameter twin-piston calipers

Park brake

Automotive-style foot-actuated mechanical park brake system

Front

25x8-12 Ancla M-T (Extreme Terrain) 4-ply rating steel wheels or 25x8-12 Terrahawk AT (All Terrain) 4-ply rating steel wheels

Rear

25x10-12 Ancla M-T (Extreme Terrain) 4-ply rating steel wheels or 25x10-12 Terrahawk AT (All Terrain) 4-ply rating steel wheels

Wheelbase

1.86 m
72.8 in.

Weight

Wet weight (includes fuel/fluids): 644 kg
Wet weight (includes fuel/fluids): 1421 lb

Length

2870 mm
113 in.

Width

1435 mm
56.5 in.

Height

1867 mm
73.5 in.

Tread centers

Front: 1220 mm
Front: 48 in.
Rear: 1168 mm
Rear: 46 in.

Ground clearance

267 mm minimum
10.5 in. minimum

Fuel capacity

28 L
7.4 U.S. gal.

Cargo box dimensions

82L x 120.9W x 29.7D (0.25 m3) cm
32.3L x 47.6W x 11.7D (8.9 ft3) in.

Cargo box capacity (weight)

227 kg
500 lb

Payload capacity

408 kg
900 lb

Towing capacity

1500 lb
680 kg

Hitch

Standard 2 in. (50 mm) rear receiver with optional 2 in. (50 mm) front receiver with recovery loops

Color

Green/Yellow; Olive/Black, Camo

Power steering

Not Available

Battery / Alternator / Power port

340 CCA
65 amp @ 3400 rpm regulated
12 VDC standard outlet

Instrumentation

Digital instrument cluster displays critical vehicle information such as speed, engine rpm, fuel level, coolant temperature, trip, odometer, time

Storage

2 cupholders, sealed underhood storage, glove box

Seating

Bench seat

Country of Manufacture

U.S.
